This document describes the etcd test integration with Antithesis. Antithesis provides a testing platform that allows you to explore edge cases, race conditions, and rare bugs that are difficult or impossible to reproduce in a normal environment.
Antithesis runs the robustness tests inside their deterministic simulation testing environment and fault injection.
For more details on robustness tests, see the robustness directory.
The setup consists of a 3-node etcd cluster and a client container, orchestrated via Docker Compose.
During the etcd Antithesis test suite the etcd server is built with the following patches:
gofail comments (which signify code locations important for failure injection in robustness tests) with Antithesis assert.Reachable. This guides Antithesis to explore the execution space around these points.verify package assertions to Antithesis assert.Always, encouraging the platform to try and break those assertions.antithesis-go-instrumentor to enable coverage tracking and feedback for the Antithesis platform.The Antithesis etcd tests configure the Test Composer in the following way:
entrypoint:setup_complete message to Antithesis to start the testing phase.singleton_driver_traffic:finally_validation:assert.Always assertions.Run this command from the antithesis/test-template directory:
make antithesis-build-client-docker-image make antithesis-build-etcd-image
Both commands build etcd-server and etcd-client from the current branch. To build a different version of etcd you can use:
make antithesis-build-etcd-image REF=${GIT_REF}
You can verify your new image is built:
docker images | grep etcd-client
It should show something like:
etcd-client latest <IMAGE_ID> <DATE>
Run the following command from the root directory for Antithesis tests (tests/antithesis):
make antithesis-docker-compose-up
The command uses the etcd client and server images built from step 1.
The client will continuously check the health of the etcd nodes and print logs similar to:
[+] Running 4/4
✔ Container etcd0 Created 0.0s
✔ Container etcd2 Created 0.0s
✔ Container etcd1 Created 0.0s
✔ Container client Recreated 0.1s
Attaching to client, etcd0, etcd1, etcd2
etcd2 | {"level":"info","ts":"2025-04-14T07:23:25.134294Z","caller":"flags/flag.go:113","msg":"recognized and used environment variable","variable-name":"ETCD_ADVERTISE_CLIENT_URLS","variable-value":"http://etcd2.etcd:2379"}
etcd2 | {"level":"info","ts":"2025-04-14T07:23:25.138501Z","caller":"flags/flag.go:113","msg":"recognized and used environment variable","variable-name":"ETCD_INITIAL_ADVERTISE_PEER_URLS","variable-value":"http://etcd2:2380"}
etcd2 | {"level":"info","ts":"2025-04-14T07:23:25.138646Z","caller":"flags/flag.go:113","msg":"recognized and used environment variable","variable-name":"ETCD_INITIAL_CLUSTER","variable-value":"etcd0=http://etcd0:2380,etcd1=http://etcd1:2380,etcd2=http://etcd2:2380"}
etcd0 | {"level":"info","ts":"2025-04-14T07:23:25.138434Z","caller":"flags/flag.go:113","msg":"recognized and used environment variable","variable-name":"ETCD_ADVERTISE_CLIENT_URLS","variable-value":"http://etcd0.etcd:2379"}
etcd0 | {"level":"info","ts":"2025-04-14T07:23:25.138582Z","caller":"flags/flag.go:113","msg":"recognized and used environment variable","variable-name":"ETCD_INITIAL_ADVERTISE_PEER_URLS","variable-value":"http://etcd0:2380"}
etcd0 | {"level":"info","ts":"2025-04-14T07:23:25.138592Z","caller":"flags/flag.go:113","msg":"recognized and used environment variable","variable-name":"ETCD_INITIAL_CLUSTER","variable-value":"etcd0=http://etcd0:2380,etcd1=http://etcd1:2380,etcd2=http://etcd2:2380"}
...
...
(skipping some repeated logs for brevity)
...
...
etcd2 | {"level":"info","ts":"2025-04-14T07:23:25.484698Z","caller":"etcdmain/main.go:50","msg":"successfully notified init daemon"}
etcd1 | {"level":"info","ts":"2025-04-14T07:23:25.484092Z","caller":"embed/serve.go:210","msg":"serving client traffic insecurely; this is strongly discouraged!","traffic":"grpc+http","address":"[::]:2379"}
etcd0 | {"level":"info","ts":"2025-04-14T07:23:25.484563Z","caller":"etcdmain/main.go:50","msg":"successfully notified init daemon"}
etcd2 | {"level":"info","ts":"2025-04-14T07:23:25.485101Z","caller":"v3rpc/health.go:61","msg":"grpc service status changed","service":"","status":"SERVING"}
etcd1 | {"level":"info","ts":"2025-04-14T07:23:25.484130Z","caller":"etcdmain/main.go:44","msg":"notifying init daemon"}
etcd2 | {"level":"info","ts":"2025-04-14T07:23:25.485782Z","caller":"embed/serve.go:210","msg":"serving client traffic insecurely; this is strongly discouraged!","traffic":"grpc+http","address":"[::]:2379"}
etcd1 | {"level":"info","ts":"2025-04-14T07:23:25.484198Z","caller":"etcdmain/main.go:50","msg":"successfully notified init daemon"}
client | Client [entrypoint]: starting...
client | Client [entrypoint]: checking cluster health...
client | Client [entrypoint]: connection successful with etcd0
client | Client [entrypoint]: connection successful with etcd1
client | Client [entrypoint]: connection successful with etcd2
client | Client [entrypoint]: cluster is healthy!
And it will stay running indefinitely.
make antithesis-run-container-traffic make antithesis-run-container-validation
Alternatively, with the etcd cluster from step 3, to run the tests locally without rebuilding the client image:
make antithesis-run-local-traffic make antithesis-run-local-validation
Unfortunatelly robustness tests don't support running on non empty database. So for now you need to cleanup the storage before repeating the run or you will get “non empty database at start, required by model used for linearizability validation” error.
make antithesis-clean
etcd-client:latest, make sure you built it locally (see the “Build and Tag” step) or push it to a registry that Compose can access.Please make sure that you have the following tools installed on your local:
You can use kind to create a local cluster to deploy the etcd-server and test client. Once you have kind installed, you can use the following command to create a local cluster:
kind create cluster
Alternatively, you can use any existing kubernetes cluster you have access to.
Please build the client and server images first. Then load the images into the kind cluster:
If you use kind, the cluster will need to have access to the images using the following commands:
kind load docker-image etcd-client:latest kind load docker-image etcd-server:latest
If you use something other than kind, please make sure the images are accessible to your cluster. This might involve pushing the images to a container registry that your cluster can pull from.
kubectl apply -f ./config/manifests
kind delete cluster --name kind
